NOSHOK® 25-120-300-psi/kPa NOS 25-120-300-PSI/KPA | Tipco Technologies
NOSHOK® 25-120-300-psi/kPa
Send Print
  1. pin-int

NOSHOK® 25-120-300-psi/kPa

NOSHOK® Pressure Gauge, 2.5" Steel Panel Mount Case, Copper Alloy Internals, 300 psi/kPa, 1/4 NPT Male Back Conn

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 25-120-300-PSI/KPA
  • MPN: 25-120-300-psi/kPa
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK® Pressure Gauge, 2.5" Steel Panel Mount Case, Copper Alloy Internals, 300 psi/kPa, 1/4 NPT Male Back Conn

California residents see Prop 65 WARNINGS

Material      :      Black painted steel with chrome triangular bezel and U-clamp
Connection Size      :      1/4 in
Series      :      100 Series Dry Pressure Gauges
Connection Type      :      National Pipe Thread (NPT)
Accuracy      :      2.5 Percent
Lens/Display Material      :      Acrylic
Scale Option      :      psi/kPa
Pressure Low      :      0 PSI
Pressure High      :      300 PSI
Connection Mount      :      Back
Gauge Size      :      2.5 in
Movement      :      Brass & nylon, or all-brass with highly polished bearing surfaces
Dial / Display Description      :      White Background with Black Primary Scale & Red Secondary Scale. Ultraviolet (UV) Resistant.
Ambient Temperature Low      :      -40 deg C
Ambient Temperature Low      :      -40 deg F
Ambient Temperature High      :      140 deg F
Ambient Temperature High      :      60 deg C
Media Temperature Low      :      -20 deg C
Media Temperature Low      :      -4 deg F
Media Temperature High      :      140 deg F
Media Temperature High      :      60 deg C
Cover Ring Material      :      Polished 304 Stainless Steel
Bezel Material      :      Chrome-plated steel triangular bezel
Scale      :      psi/kPa
