Adaptall 5307L-42-24

Adaptall 5307L Carbon Steel Adapter, L42 Female Metric DIN 24° Tube x 1-1/2 in Male NPT

  • Manufacturers: Adaptall Inc.
  • Brand Name: Adaptall
  • Tipco Part No: ADC 5307L-42-24
  • MPN: 5307L-42-24
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Adaptall 5307L Carbon Steel Adapter, Connection Size 1: L42, Gender 1: Female, Connection Type 1: Metric DIN 24° Tube x Connection Size 2: 1-1/2 in, Gender 2: Male, Connection Type 2: NPT

Series      :      5307L
Connection Size 1      :      L42
Connection Size 2      :      1-1/2 in
Gender 1      :      Female
Gender 2      :      Male
Connection 1      :      42 mm Light
Shape      :      Straight
Connection 2      :      1-1/2 in NPT
Thread Size 1      :      M52 x 2
Thread Size 2      :      1-1/2-11-1/2
Dimension Standards      :      ISO 8434-1, DIN 2353, ANSI B1.20.3
Length      :      65 mm
Fitting Type      :      Adapter
Hex Size      :      50 x 60 mm
Material      :      Carbon Steel
Connection Type 1      :      Metric DIN 24° Tube
Connection Type 2      :      NPT
