Aeroquip® 26791-16-16ZF

Aeroquip® 26791-16-16ZF Zinc Clear Trivalent Chromate Carbon Steel Female 37 deg JIC Swivel 2-Piece Crimp Hose 90 deg Elbow, 1 in

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 26791-16-16ZF
  • MPN: 26791-16-16ZF
  • UPC: 678146192936
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® 2-Piece Crimp Hose 90 deg Elbow, Connection Type 1: Hose, Connection Size 1: 1 in, Hose Dash Size: 16, Connection Type 2: 37 deg JIC Swivel, Gender 2: Female, Connection Size 2: 1 in, Nominal Size: 1 in, Thread Size 2: 1-5/16-12, Hex Size: 1.614 in, Cut-Off Factor: 2.8 in, Carbon Steel, Finish: Zinc Clear Trivalent Chromate, For Use With: EC115, EC215, EC110, EC210, and EC118 Series Hoses, Dimensions: 4.65 in L x 1.6 in W x 2.6 in H

Hose Connection      :      1 in in
Gender 2      :      Female
Connection Size 2      :      1 in
Nominal Size      :      1 in
Thread Size 2      :      1-5/16-12
Hex Size      :      1.614 in
Cut-Off Factor      :      2.8 in
Material      :      Carbon Steel
Finish      :      Zinc Clear Trivalent Chromate
For Use With      :      EC115, EC215, EC110, EC210, and EC118 Series Hoses
Fitting Type      :      90 deg Elbow
Dimensions      :      4.65 in L x 1.6 in W x 2.6 in H
Connection Type 1      :      Hose
Connection Size 1      :      1 in
Hose Dash Size      :      16
Connection 2      :      1 in JIC Swivel
Connection Type 2      :      37 deg JIC Swivel

Warranty: 5 Years Limited
