Aeroquip® FJ9122-0808S

Aeroquip® FJ9122 Carbon Steel Female SAE 37 deg JIC Swivel Crimp Straight Hose Fitting, 1/2 in

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER FJ9122-0808S
  • MPN: FJ9122-0808S
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Crimp Straight Hose Fitting, FJ9122 Series, Hose Connection: 1/2 in, Connection Type 1: Hose, Connection Size 1: 1/2 in, Hose Dash Size: 08, Connection Type 2: SAE 37 deg JIC Swivel, Gender 2: Female, Connection Size 2: 1/2 in, Nominal Size: 1/2 in, Thread Size 2: 3/4-16, Hex Size: 0.88 x 0.81 in, 4000 psi, Cut-Off Factor: 1.36 in, Carbon Steel, For Use With: 2661(-12, -16), FC619 (-12, -16), GH663, and GH793 (-4 thru -8, -12 thru -20) Series Hoses, Dimensions: 2.86 in L

Hose Connection      :      1/2 in
Gender 2      :      Female
Connection Size 2      :      1/2 in
Nominal Size      :      1/2 in
Thread Size 2      :      3/4-16
Hex Size      :      0.88 x 0.81 in
Pressure Rating      :      4000 psi
Cut-Off Factor      :      1.36 in
Material      :      Carbon Steel
For Use With      :      2661(-12, -16), FC619 (-12, -16), GH663, and GH793 (-4 thru -8, -12 thru -20) Series Hoses
Fitting Type      :      Straight Hose Fitting
Dimensions      :      2.86 in L
Series      :      FJ9122
Connection Type 1      :      Hose
Connection Size 1      :      1/2 in
Hose Dash Size      :      08
Connection 2      :      1/2 in JIC Swivel
Connection Type 2      :      SAE 37 deg JIC Swivel
