Gates® low pressure couplings with pre-crimped soft shell has been specifically designed to work with lower pressure hydraulic suction lines and low pressure return line hose. Its short body length provides the necessary grip for low pressure hose requirements and the bubble pattern crimp design ensures the similar optimal sealing to that of helical wire hoses on return vacuum applications.
Gates® Crimp Straight Hose Fitting, Female Gender 2, Connection Size 2: 3/4 in, 3/4 in Nominal, 1-1/16-12 Thread Size 2, 1-1/16 x 1-1/4 in Hex, 1.67 in Cut-Off Factor, For Use With: Multi Master® SD MegaFlex®, MegaTech® Pressure Hoses and GMV™ Suction Hoses, GL Series, 3.68 in L, 3/4 in Hose Connection, Connection Type 1: Hose, Connection Size 1: 3/4 in, 12 Hose Dash, 3/4 in 37 deg JIC Flare Swivel Connection 2, Connection Type 2: 37 deg JIC Flare Swivel
| Fitting Type | : | Hose Fitting |
| Gender 2 | : | Female |
| Connection Size 2 | : | 3/4 in |
| Nominal Size | : | 3/4 in |
| Thread Size 2 | : | 1-1/16-12 |
| Hex Size | : | 1-1/16 x 1-1/4 in |
| Cut-Off Factor | : | 1.67 in |
| For Use With | : | Multi Master® SD MegaFlex®, MegaTech® Pressure Hoses and GMV™ Suction Hoses |
| Series | : | GL Series |
| Dimensions | : | 3.68 in L |
| Hose Connection | : | 3/4 in |
| Connection Type 1 | : | Hose |
| Connection Size 1 | : | 3/4 in |
| Hose Dash Size | : | 12 |
| Connection 2 | : | 3/4 in 37 deg JIC Flare Swivel |
| Connection Type 2 | : | 37 deg JIC Flare Swivel |
