Aeroquip® 473A-4S AER 473A-4S | Tipco Technologies
Aeroquip® 473A-4S
Send Print
  1. pin-int

Aeroquip® 473A-4S

Aeroquip® 473A Dura-Kote Carbon Steel Female SAE 37 deg JIC Reusable Straight Hose Nipple Assembly, 1/4 in

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 473A-4S
  • MPN: 473A-4S
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Reusable Straight Hose Nipple Assembly, 473A Series, Hose Connection: 1/4 in, Connection Type 1: Hose, Connection Size 1: 1/4 in, Hose Dash Size: 04, Connection Type 2: SAE 37 deg JIC, Gender 2: Female, Connection Size 2: 1/4 in, Nominal Size: 1/4 in, Thread Size 2: 7/16-20, Hex Size: 0.5625 x 0.62 in, Cut-Off Factor: 0.87 in, Carbon Steel, Finish: Dura-Kote, For Use With: 2807 Series Hoses, Dimensions: 1.53 in L x 0.62 in W x 0.5625 in H

Fitting Type      :      Straight Nipple
Gender 2      :      Female
Connection Size 2      :      1/4 in
Nominal Size      :      1/4 in
Thread Size 2      :      7/16-20
Hex Size      :      0.5625 x 0.62 in
Cut-Off Factor      :      0.87 in
Material      :      Carbon Steel
Finish      :      Dura-Kote
For Use With      :      2807 Series Hoses
Series      :      473A
Dimensions      :      1.53 in L x 0.62 in W x 0.5625 in H
Hose Connection      :      1/4 in
Connection Type 1      :      Hose
Connection Size 1      :      1/4 in
Hose Dash Size      :      04
Connection 2      :      1/4 in JIC
Connection Type 2      :      SAE 37 deg JIC
