Aeroquip® FC9171-1212S

Aeroquip® FC9171 Dura-Kote Carbon Steel Female SAE 45 deg Swivel Reusable 45 deg Elbow, 3/4 in

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER FC9171-1212S
  • MPN: FC9171-1212S
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Reusable 45 deg Elbow, FC9171 Series, Hose Connection: 3/4 in, Connection Type 1: Hose, Connection Size 1: 3/4 in, Hose Dash Size: 12, Connection Type 2: SAE 45 deg Swivel, Gender 2: Female, Connection Size 2: 3/4 in, Nominal Size: 3/4 in, Thread Size 2: 1-1/16-14, Hex Size: 1-1/4 x 1.12 in, Cut-Off Factor: 2.19 in, Carbon Steel, Finish: Dura-Kote, For Use With: 2807, FC465, and S-TW PTFE Hoses, Dimensions: 3.42 in L x 1.25 in W x 3.18 in H

Fitting Type      :      45 deg Elbow
Gender 2      :      Female
Connection Size 2      :      3/4 in
Nominal Size      :      3/4 in
Thread Size 2      :      1-1/16-14
Hex Size      :      1-1/4 x 1.12 in
Cut-Off Factor      :      2.19 in
Material      :      Carbon Steel
Finish      :      Dura-Kote
For Use With      :      2807, FC465, and S-TW PTFE Hoses
Series      :      FC9171
Dimensions      :      3.42 in L x 1.25 in W x 3.18 in H
Hose Connection      :      3/4 in
Connection Type 1      :      Hose
Connection Size 1      :      3/4 in
Hose Dash Size      :      12
Connection 2      :      3/4 in SAE Swivel
Connection Type 2      :      SAE 45 deg Swivel
  • New Dura-Kote™ plating technology for up to 1000 hr of corrosion-resistant
  • Engineered to provide peak performance with Danfoss's core braided hose products
  • Can be assembled in the field without special tooling
  • Reduced downtime
  • Quick repair

Applications: For sustainable approach to designing hydraulic systems
