Aeroquip® 2HILLLRA720
Send Print
  1. pin-int

Aeroquip® 2HILLLRA720

Aeroquip® 2HKIL Carbon Steel 90 deg Elbow, 1/4 in Female Quick Disconnect x 7/16 in MNPTF

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: HSN 2HILLLRA720
  • MPN: 2HILLLRA720
  • UPC: 678146198259
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® 90 deg Elbow, 2HKIL Series, Connection Type 1: Quick Disconnect, Gender 1: Female, Connection Size 1: 1/4 in, Connection Type 2: NPTF, Gender 2: Male, Connection Size 2: 7/16 in, Thread Size 2: 7/16-20, 5000 psi, Carbon Steel, Dimensions: 2.09 in L x 1.06 in W x 1.06 in H, -40 to 250 deg F

Fitting Type      :      90 deg Elbow
Gender 2      :      Male
Connection Size 2      :      7/16 in
Thread Size 2      :      7/16-20
Pressure Rating      :      5000 psi
Material      :      Carbon Steel
Dimensions      :      2.09 in L x 1.06 in W x 1.06 in H
Series      :      2HKIL
Temperature Rating      :      -40 to 250 deg F
Connection 1      :      1/4 in Quick Disconnect
Connection Type 1      :      Quick Disconnect
Gender 1      :      Female
Connection Size 1      :      1/4 in
Connection 2      :      7/16 in NPT
Connection Type 2      :      NPTF

Danfoss's 2HKIL Series stainless steel couplings can be used with various liquids and gases. They are functionally identical, but do not interchange. They can be used where it is necessary to avoid crossing lines.

  • Ball lock design
  • Proprietary interchange with all stainless steel construction
  • Buna-N seal material

Applications: Chemical, military, aerospace, food and beverage
