Stucchi® 801313001
Send Print
  1. pin-int

Stucchi® 801313001

Stucchi® A13 Carbon Steel Interchange Nipple, 1/2 in Male Quick Disconnect x 5/8 in Male ORFS

  • Manufacturers: Stucchi USA
  • Brand Name: Stucchi®
  • Tipco Part No: STU 801313001
  • MPN: 801313001
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Stucchi Interchange Nipple, A13 Series, Connection Type 1: Quick Disconnect, Gender 1: Male, Connection Size 1: 1/2 in, Connection Type 2: ORFS, Gender 2: Male, Connection Size 2: 5/8 in, Hex Size: 1.42 in, 4785 psi, Carbon Steel, Dimensions: 2.68 in L x 1.57 in W, Dimension Standards: ISO 16028

Fitting Type      :      Nipple
Gender 2      :      Male
Connection Size 2      :      5/8 in
Hex Size      :      1.42 in
Pressure Rating      :      4785 psi
Material      :      Carbon Steel
Dimensions      :      2.68 in L x 1.57 in W
Dimension Standards      :      ISO 16028
Series      :      A13
Connection 1      :      1/2 in Quick Disconnect
Connection Type 1      :      Quick Disconnect
Gender 1      :      Male
Connection Size 1      :      1/2 in
Connection 2      :      5/8 in ORFS
Connection Type 2      :      ORFS

The A Premier Series Flat Face ISO 16028 interchange couplings offer higher pressure ratings, superior flow characteristics, and lower pressure drops compared to FIRG Series or competitor's products. Specifically designed for applications needing no-leak performance and the ideal solution for limiting contamination in hydraulic circuits, the non-spill design avoids fluid loss during connection and disconnection.

  • Lock system stops unwanted disconnection
  • Modular structure for multiple port option
  • Hardened steel, 12 to 20 balls reduce brinelling
  • Ideal for limiting contamination in hydraulic circuit

Applications: For mobile, oil and gas, industrial, agricultural
