Dixon® 500-D-BR

Dixon® 500-D-BR Brass Cam and Groove Type D Coupler, 5 in Female Coupler x 5 in FNPT

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: DXN 500-D-BR
  • MPN: 500-D-BR
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® Cam and Groove Type D Coupler, Connection Type 1: Fitting, Gender 1: Female, Connection Size 1: 5 in, Connection Type 2: NPT, Gender 2: Female, Connection Size 2: 5 in, Thread Size 2: 5-8, 75 psi, Brass, Dimensions: 6-1/2 in Dia x 3-3/4 in L

California residents see Prop 65 WARNINGS

Fitting Shape      :      Type D
Connection Size 1      :      5 in
Connection Size 2      :      5 in
Thread Size 2      :      5-8
Pressure Rating      :      75 psi
Material      :      Brass
Dimensions      :      6-1/2 in Dia x 3-3/4 in L
Fitting Type      :      Coupler
Connection 1      :      5 in Fitting
Connection 2      :      5 in NPT
Connection Type 1      :      Fitting
Connection Type 2      :      NPT
Gender 1      :      Female
Gender 2      :      Female
  • Precision machined to rigid tolerances
  • Stainless pins will not rust or bind, providing great strength and safety
  • Recess holds gasket firmly in place ensures proper placement
  • Long shank design allows proper banding, thus eliminating the major cause of hose damage
  • Buna-N gasket
  • Durable stainless steel cam arm pins
  • Produced to interchange with all product produced to commercial item description A-A-59326D

Applications: For use with liquids

Safety Notes:

  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Pressure rating recommendations are based on the use of mating Dixon® fittings at ambient temperature 70 deg F with a standard seal installed.
  • For use at elevated temperature or other unusual operating conditions, consult Dixon®.
