Dixon® Boss-Lock™ Cam and Groove Notched Type C Coupler, Connection Type 1: Fitting, Gender 1: Female, Connection Size 1: 4 in, Connection Type 2: Hose Stem, Connection Size 2: 4 in, 100 psi, 316 Stainless Steel, For Use With: Notched Ferrules
California residents see Prop 65 WARNINGS
| Fitting Shape | : | Type C |
| Connection Size 1 | : | 4 in |
| Connection Size 2 | : | 4 in |
| Pressure Rating | : | 100 psi |
| Material | : | 316 Stainless Steel |
| Fitting Type | : | Coupler |
| For Use With | : | Notched Ferrules |
| Connection 1 | : | 4 in Fitting |
| Connection 2 | : | 4 in Hose Stem |
| Connection Type 1 | : | Fitting |
| Connection Type 2 | : | Hose Stem |
| Gender 1 | : | Female |
- The largest advantage of the notched design is that the coupling can be removed from a damaged hose by cutting away the ferrule, without necessarily damaging the fitting
- After inspection of the fitting to determine its suitability for reuse, it can be reinstalled into another hose by using a new ferrule
- Supplied with pull-ring safety clips
- Buna-N seal material
- Produced to interchange with all product produced to commercial item description A-A-59326D
Safety Notes:
- Under no circumstances should cam and groove couplings be used for compressed air or steam service.
- Dixon® stems and ferrules are specifically designed to be used together as a coupling system.
- Due to differences in dimensions and tolerances for safety reasons, do not use other manufacturer's stems or ferrules with Dixon® products.
- Pressure rating recommendations are based on the use of mating Dixon® fittings at ambient temperature 70 deg F with a standard Buna-N seal installed.
- For use at elevated temperature or other unusual operating conditions, consult Dixon®. You must purchase a fitting and the matching ferrule to create an assembly.
