Aeroquip® 4739-12B
Send Print
  1. pin-int

Aeroquip® 4739-12B

Aeroquip® 4739 Brass Male SAE 45 deg Socketless Reusable Straight Hose Fitting, 3/4 in

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 4739-12B
  • MPN: 4739-12B
  • UPC: 678146055996
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability
  • Due to supply chain constraints, TIPCO reserves the right to ship the Brennan equivalent of this part.

Aeroquip® Socketless Reusable Straight Hose Fitting, 4739 Series, Hose Connection: 3/4 in, Connection Type 1: Hose, Connection Size 1: 3/4 in, Hose Dash Size: 12, Connection Type 2: SAE 45 deg, Gender 2: Male, Connection Size 2: 3/4 in, Nominal Size: 3/4 in, Thread Size 2: 1-1/16-14, Hex Size: 1-1/4 in, Cut-Off Factor: 1.19 in, Brass, For Use With: 2556 Series Hoses, Dimensions: 2.76 in L x 1.25 in W x 1.25 in H

California residents see Prop 65 WARNINGS

Fitting Type      :      Straight Hose Fitting
Gender 2      :      Male
Connection Size 2      :      3/4 in
Nominal Size      :      3/4 in
Thread Size 2      :      1-1/16-14
Hex Size      :      1-1/4 in
Cut-Off Factor      :      1.19 in
Material      :      Brass
For Use With      :      2556 Series Hoses
Series      :      4739
Dimensions      :      2.76 in L x 1.25 in W x 1.25 in H
Hose Connection      :      3/4 in
Connection Type 1      :      Hose
Connection Size 1      :      3/4 in
Hose Dash Size      :      12
Connection 2      :      3/4 in SAE
Connection Type 2      :      SAE 45 deg
