Aeroquip® 1700E
Send Print
  1. pin-int

Aeroquip® 1700E

Aeroquip® 1000 Brass Coupling, 1/4 in Female Quick Disconnect x 3/8 in Male Hose Barb

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: HSN 1700
  • MPN: 1700E
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Coupling, 1000 Series, Connection Type 1: Quick Disconnect, Gender 1: Female, Connection Size 1: 1/4 in, Connection Type 2: Hose Barb, Gender 2: Male, Connection Size 2: 3/8 in, Hex Size: 25.4 mm, 2000 psi at 70 deg F, Brass, Dimensions: 2.6 in L x 1 in W, -40 to 250 deg F, For Use With: Compressed Air, Gas, and Liquid

Fitting Type      :      Coupling
Gender 2      :      Male
Connection Size 2      :      3/8 in
Hex Size      :      25.4 mm
Pressure Rating      :      2000 psi at 70 deg F
Material      :      Brass
Dimensions      :      2.6 in L x 1 in W
Series      :      1000
Temperature Rating      :      -40 to 250 deg F
For Use With      :      Compressed Air, Gas, and Liquid
Connection 1      :      1/4 in Quick Disconnect
Connection Type 1      :      Quick Disconnect
Gender 1      :      Female
Connection Size 1      :      1/4 in
Connection 2      :      3/8 in Hose Barb
Connection Type 2      :      Hose Barb

Danfoss’s 1000 Series is an industrial interchange pneumatic coupling that is rugged and reliable designed for use with compressed air, gases and liquids.

  • Ball latching mechanism
  • All sizes accept US industrial interchange
  • Buna-N seal material

Applications: Construction, fluid transfer, general pneumatics, industrial plants
