Aeroquip® 17P HSN 17P | Tipco Technologies
Aeroquip® 17P
Send Print
  1. pin-int

Aeroquip® 17P

Aeroquip® 1000 Zinc-Plated Carbon Steel Coupling Plug with Bleeder Ball Check Valve, 1/4 in Male Quick Disconnect x 3/8 in Hose

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: HSN 17P
  • MPN: 17P
  • UPC: 678146097309
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Coupling Plug with Bleeder Ball Check Valve, 1000 Series, Connection Type 1: Quick Disconnect, Gender 1: Male, Connection Size 1: 1/4 in, Connection Type 2: Hose, Connection Size 2: 3/8 in, 2000 psi, Carbon Steel, Finish: Zinc-Plated, Dimensions: 2.06 in L x 0.87 in W x 0.87 in H, Dimension Standards: ISO 6150 Series B, -40 to 250 deg F

Fitting Type      :      Plug
Connection Size 2      :      3/8 in
Pressure Rating      :      2000 psi
Material      :      Carbon Steel
Finish      :      Zinc-Plated
Dimensions      :      2.06 in L x 0.87 in W x 0.87 in H
Dimension Standards      :      ISO 6150 Series B
Series      :      1000
Temperature Rating      :      -40 to 250 deg F
Connection 1      :      1/4 in Quick Disconnect
Connection Type 1      :      Quick Disconnect
Gender 1      :      Male
Connection Size 1      :      1/4 in
Connection 2      :      3/8 in Hose
Connection Type 2      :      Hose

Danfoss's 1000 Series is an industrial interchange pneumatic coupling that is rugged and reliable designed for use with compressed air, gases, and liquids.

  • Ball latching mechanism
  • All sizes accept US industrial interchange
  • 1/4 in and 1/2 in accept ISO 6150 B and A-A-59439 plugs/males
  • Buna-N seal material

Applications: General pneumatics, construction, industrial plants, fluid transfer
