Aeroquip® 5700E
Send Print
  1. pin-int

Aeroquip® 5700E

Aeroquip® 5000 Brass Coupling, 1/2 in Female Quick Disconnect x 3/8 in Hose Barb

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: HSN 5700
  • MPN: 5700E
  • UPC: 678146165718
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Coupling, 5000 Series, Connection Type 1: Quick Disconnect, Gender 1: Female, Connection Size 1: 1/2 in, Connection Type 2: Hose Barb, Connection Size 2: 3/8 in, Brass, Dimensions: 3.33 in L x 1.5 in W x 1.5 in H, -40 to 250 deg F, For Use With: Compressed Air, Gas, and Liquid

Fitting Type      :      Coupling
Connection Size 2      :      3/8 in
Material      :      Brass
Dimensions      :      3.33 in L x 1.5 in W x 1.5 in H
Series      :      5000
Temperature Rating      :      -40 to 250 deg F
For Use With      :      Compressed Air, Gas, and Liquid
Connection 1      :      1/2 in Quick Disconnect
Connection Type 1      :      Quick Disconnect
Gender 1      :      Female
Connection Size 1      :      1/2 in
Connection 2      :      3/8 in Hose Barb
Connection Type 2      :      Hose Barb

Danfoss's 5000 Series industrial interchange pin lock pneumatic quick disconnect couplings are designed for compressed air, gases, and liquids. This series sets the industry standard for pin lock style pneumatic couplings.

  • Easy, automatic, push-to-connect design provides instantaneous connection and disconnection of lines, plus automatic shut-off of socket/female end of line
  • Standard seal material Buna-N

Applications: Fluid transfer, general pneumatics, industrial breathing air, maintenance and repair
