Aeroquip® A5L

Aeroquip® 700 Brass Pneumatic Ball Lock Coupling with 1-Way Valve, 1/4 in Male Quick Disconnect x 9/16 in Female 30 deg Flare

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: HSN A5L
  • MPN: A5L
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Pneumatic Ball Lock Coupling with 1-Way Valve, 700 Series, Connection Type 1: Quick Disconnect, Gender 1: Male, Connection Size 1: 1/4 in, Connection Type 2: 30 deg Flare, Gender 2: Female, Connection Size 2: 9/16 in, Thread Size 2: 9/16-18 UNF, Hex Size: 0.56 in, 1500 psi, Brass, Dimensions: 1.38 in L x 0.77 in W x 0.77 in H, -40 to 250 deg F

Fitting Type      :      Coupling
Gender 2      :      Female
Connection Size 2      :      9/16 in
Thread Size 2      :      9/16-18 UNF
Hex Size      :      0.56 in
Pressure Rating      :      1500 psi
Material      :      Brass
Dimensions      :      1.38 in L x 0.77 in W x 0.77 in H
Series      :      700
Temperature Rating      :      -40 to 250 deg F
Connection 1      :      1/4 in Quick Disconnect
Connection Type 1      :      Quick Disconnect
Gender 1      :      Male
Connection Size 1      :      1/4 in
Connection 2      :      9/16 in Flare
Connection Type 2      :      30 deg Flare

Danfoss 700 Series quick connect couplings are designed for use in oxyacetylene service. The 600/700 series can also be used with compressed air and other gases.

  • Safety sleeve lock prevents accidental disconnection
  • Non-interchangeable design prevents crossing of lines
  • Color-coded sleeves for easy identification
  • Buna-N seal material

Applications: Breathing equipment, welding, shipyards, general pneumatic, construction, nitrous oxide
