Aeroquip® Coupling Plug, Auto-Flo 23 Series, Connection Type 1: Quick Disconnect, Gender 1: Male, Connection Size 1: 1/4 in, Connection Type 2: Hose Barb, Connection Size 2: 5/16 in, Carbon Steel, Finish: Zinc-Plated, Dimensions: 2.22 in L x 0.5 in W x 0.5 in W, Dimension Standards: ISO 6150 Series B, -40 to 250 deg F
| Fitting Type | : | Plug |
| Connection Size 2 | : | 5/16 in |
| Material | : | Carbon Steel |
| Finish | : | Zinc-Plated |
| Dimensions | : | 2.22 in L x 0.5 in W x 0.5 in W |
| Dimension Standards | : | ISO 6150 Series B |
| Series | : | Auto-Flo 23 |
| Temperature Rating | : | -40 to 250 deg F |
| Connection 1 | : | 1/4 in Quick Disconnect |
| Connection Type 1 | : | Quick Disconnect |
| Gender 1 | : | Male |
| Connection Size 1 | : | 1/4 in |
| Connection 2 | : | 5/16 in Hose Barb |
| Connection Type 2 | : | Hose Barb |
Danfoss's Auto-Flo 23/24 Series of pneumatic couplings were designed with high flow and easy automatic connection for compressed air in mind. The universal design makes the Auto-Flo an extremely flexible coupling Series.
- Auto-Flo 23 is the first automatic universal quick disconnect coupling designed to operate with industrial, ARO 210 and Tru-Flate interchange plugs/males
- Easy, automatic, push-to-connect design provides instantaneous connection and disconnection of lines, plus automatic shut-off of socket/female end of line
- Sleeve guard protects against accidental disconnection
- Buna-N seal material
Applications: General pneumatics, industrial plants, construction
