TIPCO Sealing

14" 150# Red SBR Full Face Gasket, 1/8" Thick

  • Manufacturers: TIPCO Technologies
  • Brand Name: TIPCO Sealing
  • Tipco Part No: TIPCO 1-1400-200-125
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

14" 150# Red SBR Full Face Gasket, 1/8" Thick, Inside Diameter: 14.00 in, Outside Diameter: 21.00 in, Color: Red, Material: Red Rubber (SBR), Maximum Temperature: 180 °F, Operating Pressure: 150 psi, Number of Bolt Holes: 12

Product Type      :      Red SBR Gasket
Nominal Size      :      14 in
Inside Diameter      :      14.00 in
Outside Diameter      :      21.00 in
Thickness      :      1/8 in
Number of Bolt Holes      :      12
Material      :      Red Rubber (SBR)
Color      :      Red
Maximum Temperature      :      180 °F
Operating Pressure      :      150 psi
  • pdfTIPCO GASKETS.pdf https://shop.tipcotech.com//ASSETS/DOCUMENTS/ITEMS/EN/TIPCO GASKETS.pdf
