TIPCO Sealing SSG-SFY-L-150-100SS
TIPCO Sealing SSG-SFY-L-150-100SS 316 Stainless Steel/FKM Sock Screen Gasket, 1-1/2 in
- Manufacturers: TIPCO Technologies
- Brand Name: TIPCO Sealing
- Tipco Part No: RUB SSG-SFY-L-150-100SS
- MPN: SSG-SFY-L-150-100SS
- Min. Order Qty: 1
- Qty. Interval: 1
- Register to see Availability
TIPCO Sealing Sock Screen Gasket, Nominal Size: 1-1/2 in, 6 in Length, 316 Stainless Steel/FKM, For Use With: Standard Tri-Clamp® Connections
| Product Type | : | Gasket |
| Material | : | 316 Stainless Steel/FKM |
| For Use With | : | Standard Tri-Clamp® Connections |
| Nominal Size | : | 1-1/2 in |
| Length | : | 6 in |
Sock screen strainer designs are inserted into the ID of your stainless steel tubing and provide filtration for a greater soil retention. The extended sock shaped mesh gasket offers up to 300% more open area for 300% more soil collection capability than conventional screens. Sock screen gaskets provide greater flow for situations where a large amount of particulates are involved. Due to the large capacity and open screen area, sock screen gaskets require less service, therefore, reducing down time and costly change outs, a major consideration with inline pharmaceutical processing.
- While protecting expensive processing pumps and equipment from foreign matter, sock screens are especially effective in decreasing pump wear and burnout while increasing energy conservation
- Regularly used in the transfer of liquids from a bulk tank to a tank truck and/or in the opposite direction, sanitary sock screens are specifically designed for high-volume applications with low pressure drop
- Rubber Fab's sock screen design assures a tight fit while allowing continuous fluid flow and filtration
- Durable 316 stainless steel with the elastomer of your choice
- Fully reusable for an average of 250 - 300 procedures
- Eliminates leaks and breakage in your lines
Standards/Certifications: Animal Derived Ingredient Free
Applications: Inline fluid conditioning, pump protection, tank to tank transfer
Specification Sheet
