Aeroquip® 3270-0615-0100
Send Print
  1. pin-int

Aeroquip® 3270-0615-0100

Aeroquip® Eclipse™ 3270 Nylon Air Brake Hose and Tubing, 3/8 in, 100 ft L, 350 psi, 0.06 in Thick Wall, Green

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 3270-0615-0100
  • MPN: 3270-0615-0100
  • UPC: 639789336149
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Eclipse™ Air Brake Hose and Tubing, Series: 3270, Nominal Size: 3/8 in, 3/8 in OD, 1/4 in ID, 100 ft Length, Nylon, Green, 350 psi Working, 1400 psi Burst, 0.06 in Thick Wall, 1-1/2 in Bend Radius, Resistance Properties: Abrasion, -40 to 200 deg F

Product Type      :      Air Brake Tubing
Wall Thickness      :      0.06 in
Bend Radius      :      1-1/2 in
Resistance Properties      :      Abrasion
Temperature Rating      :      -40 to 200 deg F
Series      :      3270
Nominal Size      :      3/8 in
Outside Diameter      :      3/8 in
Inside Diameter      :      1/4 in
Length      :      100 ft
Material      :      Nylon
Color      :      Green
Pressure Rating      :      350 psi Working, 1400 psi Burst
  • Superior abrasion resistance
  • Ease of cutting
  • Enhanced flexibility and extension
  • Flow performance

Standards/Certifications: DOT FMVSS 106 Approved

  • SAE J2494-2/J844/J1131 Certified

    Applications: For truck and trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies
