Aeroquip® 4247-04106
Send Print
  1. pin-int

Aeroquip® 4247-04106

Aeroquip® Eclipse™ 4247 Nylon Air Brake Hose and Tubing, 1/4 in, 6000 ft L, 240 psi, 0.04 in Thick Wall, White

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 4247-04106
  • MPN: 4247-04106
  • UPC: 678146086112
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Eclipse™ Air Brake Hose and Tubing, Series: 4247, Nominal Size: 1/4 in, 1/4 in OD, 0.17 in ID, 6000 ft Length, Nylon, White, 240 psi Working, 1200 psi Burst, 0.04 in Thick Wall, 1 in Bend Radius, Resistance Properties: Abrasion, -40 to 200 deg F

Product Type      :      Air Brake Tubing
Wall Thickness      :      0.04 in
Bend Radius      :      1 in
Resistance Properties      :      Abrasion
Temperature Rating      :      -40 to 200 deg F
Series      :      4247
Nominal Size      :      1/4 in
Outside Diameter      :      1/4 in
Inside Diameter      :      0.17 in
Length      :      6000 ft
Material      :      Nylon
Color      :      White
Pressure Rating      :      240 psi Working, 1200 psi Burst
  • Superior abrasion resistance
  • Ease of cutting
  • Enhanced flexibility and extension
  • Flow performance

Standards/Certifications: DOT FMVSS 106 Approved

  • SAE J2494-2/J844/J1131 Certified

    Applications: For truck and trailer air brake systems, auxiliary air systems, formed tubes, formed and straight air brake harness assemblies
