Aeroquip® 2583-6 AER 2583-6 | Tipco Technologies
Aeroquip® 2583-6
Send Print
  1. pin-int

Aeroquip® 2583-6

Aeroquip® 2583 Black Synthetic Rubber Braided Hydraulic Hose, 1 ft L, 1125 psi

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 2583-6
  • MPN: 2583-6
  • UPC: 678146137579
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Braided Hydraulic Hose, 2583 Series, Dash Size: 06, 0.75 in OD, 0.38 in ID, 0.185 in Thick Wall, 1 ft Length, 1125 psi, SAE Rating: SAE 100R3, Synthetic Rubber, Chloroprene Rubber Cover, Construction: 2-Ply Polyester Braid, Black, 4 in Bend Radius, Resistance Properties: Abrasion, -40 deg F Low, 212 deg F High

Product Type      :      Hydraulic Hose
SAE Rating      :      SAE 100R3
Wall Thickness      :      0.185 in
Material      :      Synthetic Rubber
Cover Material      :      Chloroprene Rubber
Construction      :      2-Ply Polyester Braid
Color      :      Black
Bend Radius      :      4 in
Length      :      1 ft
Series      :      2583
Resistance Properties      :      Abrasion
Dash Size      :      06
Inside Diameter      :      0.38 in
Outside Diameter      :      0.75 in
Temperature Low      :      -40 deg F
Temperature High      :      212 deg F
Pressure Rating      :      1125 psi

Applications: For gasoline, crude fuel and lubricating oils, air and water
