Aeroquip® FC693-06

Aeroquip® FC693 Green EPDM Braided Hydraulic Hose, 0.38 in, 12 in L, 4000 psi

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER FC693-06
  • MPN: FC693-06
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Braided Hydraulic Hose, FC693 Series, Nominal Size: 0.38 in, Dash Size: 06, 0.75 in OD, 0.38 in ID, 0.185 in Thick Wall, 12 in Length, 4000 psi, EPDM, EPDM Cover, Construction: 2-Ply Braid Wire, Green, 5 in Bend Radius, Resistance Properties: Abrasion, -40 deg F Low, 175 deg F High

Product Type      :      Hydraulic Hose
Wall Thickness      :      0.185 in
Material      :      EPDM
Cover Material      :      EPDM
Construction      :      2-Ply Braid Wire
Color      :      Green
Bend Radius      :      5 in
Length      :      12 in
Series      :      FC693
Resistance Properties      :      Abrasion
Nominal Size      :      0.38 in
Dash Size      :      06
Inside Diameter      :      0.38 in
Outside Diameter      :      0.75 in
Temperature Low      :      -40 deg F
Temperature High      :      175 deg F
Pressure Rating      :      4000 psi

Applications: For use with phosphate ester base fluids
