Aeroquip® FC636-16
Send Print
  1. pin-int

Aeroquip® FC636-16

Aeroquip® FC636 Green EPDM Hydraulic Spiral Hose, 1 in, 12 in L, 4000 psi

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER FC636-16
  • MPN: FC636-16
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Hydraulic Spiral Hose, FC636 Series, Nominal Size: 1 in, Dash Size: 16, 1.48 in OD, 1 in ID, 0.24 in Thick Wall, 12 in Length, 4000 psi, SAE Rating: SAE 100R12 / EN 856 R12, EPDM, EPDM Cover, Construction: 4-Spiral Wire, Green, 12 in Bend Radius, Resistance Properties: Abrasion, -40 deg F Low, 175 deg F High

Product Type      :      Hydraulic Spiral Hose
Series      :      FC636
Nominal Size      :      1 in
Dash Size      :      16
Inside Diameter      :      1 in
Outside Diameter      :      1.48 in
Temperature Low      :      -40 deg F
Temperature High      :      175 deg F
Pressure Rating      :      4000 psi
SAE Rating      :      SAE 100R12 / EN 856 R12
Material      :      EPDM
Cover Material      :      EPDM
Construction      :      4-Spiral Wire
Wall Thickness      :      0.24 in
Color      :      Green
Length      :      12 in
Bend Radius      :      12 in
Resistance Properties      :      Abrasion

Applications: Ground support equipment, industrial phosphate ester-based fluids, water-glycol systems
