Recommended for extremely high-pressure and high-impulse hydraulic applications. Exceeds all performance requirements for ISO 18752 Grade D, SAE 100R12, EN 856 R12, performance requirements of EN 856 4SP and ISO 3862 Type R12. Recommended couplings GlobalSpiral™ couplings, GlobalSpiral™ Plus couplings, special one-piece coupling (MC4-20 Crimper Only) (-20), stainless steel B couplings (-20), stainless steel S couplings (-24 and -32).
Gates® Spiral Wire Hose, 32 Dash, 2 in Inside Diameter, 2.63 in Outside Diameter, Temperature Low: -40 deg F, Temperature High: 250 deg F, 3000 psi, Polychloroprene Cover, 12-1/2 in Bend Radius, Resistance Properties: Flame, For Use With: GlobalSpiral™ Couplings (-20) (G20) Section E, GlobalSpiral™ One-Piece Couplings (MC 4-20) (-20 only) Section E, GlobalSpiral™ Plus Couplings (-24 and -32) (G22) Section E, Stainless Steel Braid Couplings (-24 and -32) (G17) Section H and Stainless Steel Spiral Couplings (-20) (G18) Section F
| Product Type | : | Spiral Wire Hose |
| Dash Size | : | 32 |
| Inside Diameter | : | 2 in |
| Outside Diameter | : | 2.63 in |
| Temperature Low | : | -40 deg F |
| Temperature High | : | 250 deg F |
| Pressure Rating | : | 3000 psi |
| Cover Material | : | Polychloroprene |
| Bend Radius | : | 12-1/2 in |
| Resistance Properties | : | Flame |
| For Use With | : | GlobalSpiral™ Couplings (-20) (G20) Section E, GlobalSpiral™ One-Piece Couplings (MC 4-20) (-20 only) Section E, GlobalSpiral™ Plus Couplings (-24 and -32) (G22) Section E, Stainless Steel Braid Couplings (-24 and -32) (G17) Section H and Stainless Steel Spiral Couplings (-20) (G18) Section F |
- EFG3K hose is compatible with biodegradable hydraulic fluids like synthetic esters, polyglycols and vegetable oils as well as petroleum-based fluids
- -24 to -32 with GlobalSpiral™ Plus
- Up to 40% of EN 856 4SP bend radius at rated working pressure
- Meets flame-resistant acceptance designation MSHA 2G
