Gates® 8LOLBXREEL
Gates® 8LOLBXREEL Lock-On Hydraulic Hose, 1/2 in, 1/2 in ID, 0.77 in OD, 300 ft L, 300 psi, Synthetic Rubber, Black
- Manufacturers: Gates Corp
- Brand Name: Gates®
- Tipco Part No: GAT 8LOLB PLUSXUPS
- MPN: 8LOLBXREEL
- UPC: 072053228298
- Min. Order Qty: 1
- Qty. Interval: 1
- Register to see Availability
Recommended for petroleum-based hydraulic oils, water, glycol anti-freeze solutions, engine lubricating oils and air. Suitable for low pressure cleaning and pneumatic systems, return lines and low pressure lines. Lock-On hose and couplings are not recommended for pressure surge or critical applications such as permanent piping in residential or commercial buildings. Do not use for gasoline or diesel fuels, unless approved by Gates® H/C product application. Recommended couplings - field attachable LOL couplings (Except -3), GLP couplings (Except -3), GLX couplings (-4, -6, -8, -12), special order couplings may be needed (-3).
Gates® Lock-On Hydraulic Hose, 1/2 in Nominal, 0.77 in Outside Diameter, 1/2 in Inside Diameter, 300 ft Length, 300 psi, Synthetic Rubber, Synthetic Rubber Cover, 1-Fiber Braid Construction, Black, 5 in Bend Radius, Resistance Properties: Abrasion, Flame, Oil, Temperature Low: -40 deg F, Temperature High: 212 deg F, For Use With: Lock-On Plus Reusable Couplings
| Product Type | : | Lock-On Hydraulic Hose |
| Nominal Size | : | 1/2 in |
| Outside Diameter | : | 0.77 in |
| Inside Diameter | : | 1/2 in |
| Length | : | 300 ft |
| Pressure Rating | : | 300 psi |
| Material | : | Synthetic Rubber |
| Cover Material | : | Synthetic Rubber |
| Construction | : | 1-Fiber Braid |
| Color | : | Black |
| Bend Radius | : | 5 in |
| Resistance Properties | : | Abrasion, Flame, Oil |
| Temperature Low | : | -40 deg F |
| Temperature High | : | 212 deg F |
| For Use With | : | Lock-On Plus Reusable Couplings |
- Available in six-colors for easy color-coding
