Aeroquip® 3440-16-250BX
Send Print
  1. pin-int

Aeroquip® 3440-16-250BX

Aeroquip® 3440 Blue Polyolefin Hydraulic Hose, 1500 psi

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 3440-16-250RC
  • MPN: 3440-16-250BX
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Hydraulic Hose, 3440 Series, Dash Size: 16, 1.46 in OD, 1 in ID, 1500 psi, Polyolefin, Polyurethane Cover, Construction: 2-Ply Braid, Blue, 8 in Bend Radius, -10 deg F Low, 150 deg F High

Product Type      :      Hydraulic Hose
Material      :      Polyolefin
Cover Material      :      Polyurethane
Construction      :      2-Ply Braid
Color      :      Blue
Series      :      3440
Bend Radius      :      8 in
Dash Size      :      16
Inside Diameter      :      1 in
Outside Diameter      :      1.46 in
Temperature Low      :      -10 deg F
Temperature High      :      150 deg F
Pressure Rating      :      1500 psi
  • High-moisture barrier core tube
  • No plasticizers in the core tube
  • UV-resistant cover

Applications: For conveying urethane foam components, moisture sensitive chemicals
