Aeroquip® 2661-20
Send Print
  1. pin-int

Aeroquip® 2661-20

Aeroquip® 2661 Blue Synthetic Rubber Hydraulic Suction Hose, 1-1/4 in, 1 ft L, 200 psi

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 2661-20
  • MPN: 2661-20
  • UPC: 678146075376
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Aeroquip® Hydraulic Suction Hose, 2661 Series, Nominal Size: 1-1/4 in, Dash Size: 20, 1.8 in OD, 1.25 in ID, 0.275 in Thick Wall, 1 ft Length, 200 psi, Synthetic Rubber, Elastomer Cover, Construction: 2-Ply Braid, Helical Wire and Textile, Blue, 8 in Bend Radius, Resistance Properties: Abrasion, -40 deg F Low, 302 deg F High

Product Type      :      Hydraulic Suction Hose
Pressure Rating      :      200 psi
Material      :      Synthetic Rubber
Cover Material      :      Elastomer
Construction      :      2-Ply Braid, Helical Wire and Textile
Color      :      Blue
Bend Radius      :      8 in
Resistance Properties      :      Abrasion
Temperature Low      :      -40 deg F
Series      :      2661
Temperature High      :      302 deg F
Nominal Size      :      1-1/4 in
Dash Size      :      20
Outside Diameter      :      1.8 in
Inside Diameter      :      1.25 in
Wall Thickness      :      0.275 in
Length      :      1 ft
  • Embossed layline style

Applications: For suction and transfer applications for petroleum and fire-resistant hydraulic fluids, fuel, lubricating oils, gasoline, water and many other industrial fluids
