Dixon® GSS1500-4
Send Print
  1. pin-int

Dixon® GSS1500-4

Dixon® GSS1500-4 Dry Gauge, 0 - 1500 psi, 4 in Dial

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: DXN GSS1500-4
  • MPN: GSS1500-4
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® Dry Gauge, Pressure Range: 0 - 1500 psi, Connection Size: 1/4 in, 4 in Dial Size, 1.6 % Accuracy, -40 to 140 deg F, Lower Back Mount, 304 Stainless Steel Case, Lens Material: Polycarbonate

California residents see Prop 65 WARNINGS

Product Type      :      Dry Gauge
Connection Size      :      1/4 in
Mounting Type      :      Lower Back
Case Material      :      304 Stainless Steel
Lens Material      :      Polycarbonate
Accuracy      :      1.6 %
Pressure Range      :      0 - 1500 psi
Dial Size      :      4 in
Temperature Rating      :      -40 to 140 deg F
  • Provide the corrosion resistance and durability of a permanently sealed gauge
  • 304 stainless case
  • Polycarbonate window, 3-1/2 in across
  • 1/4 in NPT lower mount stainless connector
  • 316L stainless bourdon tube and socket, polyester segment
