NOSHOK® 25-200-10/10-inH2O-NSWC

NOSHOK® 25-200-10/10-inH2O-NSWC Black Low Diaphragm Dry Pressure Gauge, 2-1/2 in Dial, -10 to 10 inH2O

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 25-200-10/10-INH2O-NSWC
  • MPN: 25-200-10/10-inH2O-NSWC
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK Low Diaphragm Dry Pressure Gauge, 200 Series, Pressure Range: -10 to 10 inH2O, Connection Size: 1/4 in NPT, 2-1/2 in Dial Size, +/-1.6% Full Scale Accuracy, -4 to 140 deg F Ambient, -4 to 176 deg F Media, Analog Display, Bottom Mount, Steel Case, Lens Material: Acrylic, Aluminum Pointer, Finish: Black, Dimensions: 2.48 in W x 1.57 in D

California residents see Prop 65 WARNINGS

Product Type      :      Pressure Gauge
Connection Size      :      1/4 in NPT
Mounting Type      :      Bottom
Case Material      :      Steel
Series      :      200
Lens Material      :      Acrylic
Accuracy      :      +/-1.6% Full Scale
Pointer Material      :      Aluminum
Finish      :      Black
Dimensions      :      2.48 in W x 1.57 in D
Pressure Range      :      -10 to 10 inH2O
Dial Size      :      2-1/2 in
Temperature Rating      :      -4 to 140 deg F Ambient, -4 to 176 deg F Media
Display Type      :      Analog
  • Sensitive capsule-type, non-fillable dry gauge
  • Vacuum ranges through 0 - 10 psi
  • Copper alloy and brass wetted parts
  • Measuring element - copper alloy diaphragm capsule
  • Brass connection
  • Aluminum dial, white background with black scale, UV-resistant
  • Movement - brass and nickel silver with highly polished bearing surfaces
  • Black painted case, black pointer

Applications: Ideal for applications including filter monitoring, gas distribution, HVAC, leak detection, level indication and medical
