NOSHOK® 15-120-15-psi/kPa-BP3

NOSHOK® Pressure Gauge, 1.5" Steel Panel Mount Case, 15 psi/kPa, 1/8 NPT Back Conn, 0.3mm Brass Press Fit Orifice

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 15-120-15-PSI/KPA-BP3
  • MPN: 15-120-15-psi/kPa-BP3
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK® Pressure Gauge, 1.5" Steel Panel Mount Case, 15 psi/kPa, 1/8 NPT Back Conn, 0.3mm Brass Press Fit Orifice

California residents see Prop 65 WARNINGS

Material      :      Black painted steel with chrome triangular bezel and U-clamp
Product Type      :      Pressure Gauge
Connection Size      :      1/8 in NPT
Mounting Type      :      Panel
Case Material      :      Steel
Series      :      100
Connection Type      :      National Pipe Thread (NPT)
Lens Material      :      Acrylic
Accuracy      :      +/-2.5% Full Scale
Pointer Material      :      Molded Plastic
Lens/Display Material      :      Acrylic
Case Type      :      Steel Case Panel Mount
Finish      :      Black Painted
Scale Option      :      psi/kPa
Includes      :      Brass Press Fit Orifice 0.3 mm
Pressure Low      :      0 PSI
Pressure High      :      15 PSI
Connection Mount      :      Back
Connection Material      :      Brass
Gauge Size      :      1.5 in
Measuring System      :      psi, kPa
Movement      :      Brass & nylon, or all-brass with highly polished bearing surfaces
Pressure Range      :      0 - 15 psi
Dial / Display Description      :      White Background with Black Primary Scale & Red Secondary Scale. Ultraviolet (UV) Resistant.
Ambient Temperature Low      :      -40 deg C
Ambient Temperature Low      :      -40 deg F
Dial Size      :      1-1/2 in
Ambient Temperature High      :      140 deg F
Ambient Temperature High      :      60 deg C
Temperature Rating      :      -4 to 140 deg F Media, -40 to 140 deg F Ambient
Display Type      :      Analog
Media Temperature Low      :      -20 deg C
Media Temperature Low      :      -4 deg F
Media Temperature High      :      140 deg F
Media Temperature High      :      60 deg C
Cover Ring Material      :      Polished 304 Stainless Steel
Bezel Material      :      Steel
Scale      :      psi/kPa
  • General-purpose non-fillable dry gauge
  • Vacuum and compound ranges through 0 - 15000 psi
  • Standard impact-resistant ABS and steel case
  • Copper alloy and brass wetted parts
  • White background dial with black primary scale and red secondary scale, UV-resistant
  • Movement - brass and nylon or all brass with highly polished bearing surfaces
  • Case with chrome triangular bezel and U-clamp
  • Measuring element - copper alloy bourdon tube

Applications: Ideal for applications including hydraulics and pneumatics, medical, pumps and compressors, refrigeration controls, utilities and water management
