NOSHOK® 25-100-30/30-psi/kPa-BP3

NOSHOK® Pressure Gauge, 2.5" ABS Case, Copper Alloy Internals, 30/30 psi/kPa, 1/4 NPT Male Bottom Conn, 0.3mm Brass Press Fit Orifice

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 25-100-30/30-PSI/KPA-BP3
  • MPN: 25-100-30/30-psi/kPa-BP3
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK® Pressure Gauge, 2.5" ABS Case, Copper Alloy Internals, 30/30 psi/kPa, 1/4 NPT Male Bottom Conn, 0.3mm Brass Press Fit Orifice

California residents see Prop 65 WARNINGS

Material      :      Acrylonitrile Butadiene Styrene (ABS)
Connection Size      :      1/4 in
Series      :      100 Series Dry Pressure Gauges
Connection Type      :      National Pipe Thread (NPT)
Connection Mount      :      Bottom
Connection Material      :      Brass
Gauge Size      :      2.5 in
Movement      :      Brass & nylon, or all-brass with highly polished bearing surfaces
Dial / Display Description      :      White Background with Black Primary Scale & Red Secondary Scale. Ultraviolet (UV) Resistant.
Ambient Temperature Low      :      -40 deg C
Ambient Temperature Low      :      -40 deg F
Ambient Temperature High      :      140 deg F
Ambient Temperature High      :      60 deg C
Media Temperature Low      :      -20 deg C
Media Temperature Low      :      -4 deg F
Media Temperature High      :      140 deg F
Media Temperature High      :      60 deg C
Scale      :      psi/kPa
