NOSHOK® 100-12-1-25-46-1-0

NOSHOK® 2.5" Sanitary Gauge, 0 to 60 psi, 1.5 Clamp, Glycerin Fill

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 100-12-1-25-46-1-0
  • MPN: 100-12-1-25-46-1-0
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK® 2.5" Sanitary Gauge, 0 to 60 psi, 1.5 Clamp, Glycerin Fill

California residents see Prop 65 WARNINGS

Material      :      Electropolished 304 Stainless Steel
Connection Size      :      1.5 in
Series      :      10 Series Liquid Filled Pressure Gauges
Connection Type      :      Sanitary Tri-Clamp®
Fill Liquid      :      Glycerin, USP Grade
Accuracy      :      1.6 Percent
Lens/Display Material      :      Safety Glass
Scale Option      :      psi
Pressure Low      :      0 PSI
Pressure High      :      60 PSI
Gauge Size      :      2.5 in
Movement      :      Stainless Steel
Dial / Display Description      :      Aluminum, White Background with Black Scale.
Ambient Temperature Low      :      -4 deg C
Ambient Temperature Low      :      25 deg F
Ambient Temperature High      :      140 deg F
Ambient Temperature High      :      60 deg C
Operating Temperature Low      :      -4 deg C
Operating Temperature Low      :      25 deg F
Operating Temperature High      :      140 deg F
Operating Temperature High      :      60 deg C
Media Temperature Low      :      -40 deg C
Media Temperature Low      :      -40 deg F
Media Temperature High      :      150 deg C
Media Temperature High      :      300 deg F
Cover Ring Material      :      Polished 304 Stainless Steel
Scale      :      psi
