NOSHOK® 60-500-20000-psi/bar NOS 60-500-20000-PSI/BAR | Tipco Technologies
NOSHOK® 60-500-20000-psi/bar
Send Print
  1. pin-int

NOSHOK® 60-500-20000-psi/bar

NOSHOK® Pressure Gauge, 6" 304SS Case, 316SS Internals, 20000 psi/bar, 1/2 NPT Male Bottom Conn, Glycerin Filled

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 60-500-20000-PSI/BAR
  • MPN: 60-500-20000-psi/bar
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK® Pressure Gauge, 6" 304SS Case, 316SS Internals, 20000 psi/bar, 1/2 NPT Male Bottom Conn, Glycerin Filled

California residents see Prop 65 WARNINGS

Material      :      304 Stainless Steel with Safety Relief Plug, Optional 316 Stainless Steel
Connection Size      :      1/2 in
Series      :      500 Series Liquid Filled Pressure Gauges
Connection Type      :      National Pipe Thread (NPT)
Fill Liquid      :      Glycerin
Accuracy      :      1 Percent
Lens/Display Material      :      Laminated Safety Glass
Case Type      :      Stainless Steel (SS) Case, Liquid Filled, Bottom Connection
Scale Option      :      psi/bar
Pressure Low      :      0 PSI
Pressure High      :      20,000 PSI
Connection Mount      :      Bottom
Gauge Size      :      6 in
Ambient Temperature Low      :      -20 deg C
Ambient Temperature Low      :      -4 deg F
Ambient Temperature High      :      140 deg F
Ambient Temperature High      :      60 deg C
Media Temperature Low      :      -20 deg C
Media Temperature Low      :      -40 deg F
Media Temperature High      :      100 deg C
Media Temperature High      :      212 deg F
Scale      :      psi/bar
