NOSHOK® 45-760-300-psi/kPa NOS 45-760-300-PSI/KPA | Tipco Technologies
NOSHOK® 45-760-300-psi/kPa
Send Print
  1. pin-int

NOSHOK® 45-760-300-psi/kPa

NOSHOK® Process Gauge, 4.5" 316SS Internals, 300 psi/kPa, 1/2 NPT Male Bottom Conn, Glycerin Filled

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 45-760-300-PSI/KPA
  • MPN: 45-760-300-psi/kPa
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK® Process Gauge, 4.5" 316SS Internals, 300 psi/kPa, 1/2 NPT Male Bottom Conn, Glycerin Filled

California residents see Prop 65 WARNINGS

Material      :      Turret Style Black Polypropylene Case Solid Front, Safety Case with Blow-Out Back
Connection Size      :      1/2 in
Series      :      700 Series Liquid Filled Pressure Gauges
Connection Type      :      National Pipe Thread (NPT)
Fill Liquid      :      Glycerin
Accuracy      :      0.5 Percent
Lens/Display Material      :      Acrylic
Case Type      :      Stainless Steel (SS), Liquid Filled, Bottom Connect
Scale Option      :      psi/kPa
Pressure Low      :      0 PSI
Pressure High      :      300 PSI
Connection Mount      :      Bottom
Connection Material      :      316 Stainless Steel
Gauge Size      :      4.5 in
Movement      :      Stainless steel with highly polished bearing surfaces. An internal zero stop is standard.
Dial / Display Description      :      Aluminum, White Background with Black Scale. Ultraviolet (UV) Resistant.
Ambient Temperature Low      :      -20 deg C
Ambient Temperature Low      :      -4 deg F
Ambient Temperature High      :      150 deg F
Ambient Temperature High      :      65 deg C
Media Temperature Low      :      -20 deg C
Media Temperature Low      :      -4 deg F
Media Temperature High      :      100 deg C
Media Temperature High      :      212 deg F
Cover Ring Material      :      Polished 304 Stainless Steel
Scale      :      psi/kPa
