NOSHOK® 25-310-30-vac-BFF
NOSHOK® Vacuum Gauge, 2.5" Brass Case, Copper Alloy Internals, 30 vac, 1/4 NPT Male Back Conn, Glycerin Filled, Brass Front Flange
- Manufacturers: NOSHOK
- Brand Name: NOSHOK®
- Tipco Part No: NOS 25-310-30-VAC-BFF
- MPN: 25-310-30-vac-BFF
- Min. Order Qty: 1
- Qty. Interval: 1
- Register to see Availability
NOSHOK® Vacuum Gauge, 2.5" Brass Case, Copper Alloy Internals, 30 vac, 1/4 NPT Male Back Conn, Glycerin Filled, Brass Front Flange
California residents see Prop 65 WARNINGS
| Material | : | Die Cast Brass (Natural Brass Finish) with Safety Relief Plug |
| Connection Size | : | 1/4 in |
| Series | : | 300 Series Liquid Filled Pressure Gauges |
| Connection Type | : | National Pipe Thread (NPT) |
| Fill Liquid | : | Glycerin |
| Accuracy | : | 1.6 Percent |
| Lens/Display Material | : | Acrylic with O-Ring Seal |
| Case Type | : | Brass, Back Connection |
| Pressure Low | : | 0 PSI |
| Pressure High | : | 30 PSI |
| Connection Mount | : | Back |
| Gauge Size | : | 2.5 in |
| Movement | : | Brass and Nickel-Silver with Highly Polished Bearing Surfaces |
| Dial / Display Description | : | Aluminum, White Background with Black Scale. Ultraviolet (UV) Resistant. |
| Ambient Temperature Low | : | -18 deg C |
| Ambient Temperature Low | : | 0 deg F |
| Ambient Temperature High | : | 160 deg F |
| Ambient Temperature High | : | 71 deg C |
| Media Temperature Low | : | -20 deg C |
| Media Temperature Low | : | -4 deg F |
| Media Temperature High | : | 140 deg F |
| Media Temperature High | : | 60 deg C |
| Optional Temperature Low | : | -40 deg C |
| Optional Temperature Low | : | -40 deg F |
| Optional Temperature High | : | 100 deg C |
| Optional Temperature High | : | 212 deg F |
| Scale | : | vac |
