NOSHOK® 650-2000-1-1-2-39

NOSHOK® Pressure Transducer, 0 psig to 2000 psig, 0.5% Accuracy (BFSL), 4 mA to 20 mA Output, 1/4 NPT Male, Integral Cable 18 in (IP69K)

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 650-2000-1-1-2-39
  • MPN: 650-2000-1-1-2-39
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK® Pressure Transducer, 0 psig to 2000 psig, 0.5% Accuracy (BFSL), 4 mA to 20 mA Output, 1/4 NPT Male, Integral Cable 18 in (IP69K)

California residents see Prop 65 WARNINGS

Material      :      PBT - Fiber Reinforced Plastic
Product Type      :      Pressure Transducer
Connection Size      :      1/4 in
Temperature Rating      :      -40 to 212 deg F Ambient, -40 to 257 deg F Media, -40 to 248 deg F Storage
Series      :      650
Connection Type      :      National Pipe Thread (NPT)
Enclosure      :      IP67
Pressure Low      :      0 PSI
Dimensions      :      0.8 in Dia x 2.45 in L
Pressure High      :      2,000 PSI
Connection Material      :      316 Stainless Steel
Ambient Temperature Low      :      -40 deg C
Ambient Temperature Low      :      -40 deg F
Ambient Temperature High      :      100 deg C
Ambient Temperature High      :      212 deg F
Pressure Range      :      0 - 2000 psig
Operating Temperature Low      :      -40 deg C
Operating Temperature Low      :      -40 deg F
Process Connection      :      1/4 in MPT
Operating Temperature High      :      220 deg C
Operating Temperature High      :      248 deg F
Accuracy      :      +/-0.5% Full Scale (BFSL)
Media Temperature Low      :      -40 deg C
Media Temperature Low      :      -40 deg F
Power Required      :      8 - 36 VDC
Media Temperature High      :      125 deg C
Media Temperature High      :      257 deg F
Industry Standards      :      European Conformity (CE) Compliant to Electromagnetic Compatibility (EMC) Norm European Standards (EN) 61326:2014/A1:1998, Request for Information (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD) Protection
Output Signal      :      4 - 20 mA, 2-Wire
Electrical Protection      :      Reverse polarity, over-voltage and short circuit protection
Electrical Connection      :      18 in Integral Cable IP69K
Service Life      :      >100,000,000 Load Cycles
Vibration According to International Electrotechnical Commission (IEC) 60068-2-6      :      20 g
Shock According to International Electrotechnical Commission (IEC) 60068      :      500 g
Stability      :      ±0.2% full scale for 1 year, non-accumulating
Compensated Temperature Low      :      0 deg C
Compensated Temperature Low      :      32 deg F
Compensated Temperature High      :      176 deg F
Compensated Temperature High      :      80 deg C
Load Limitations      :      =(VPower-10)/0.020 amp for 4 mA to 20 mA output =5,000 Ω for 1 Vdc to 5 Vdc output =10,000 Ω for 0 Vdc to 10 Vdc output =4,500 Ω for 0.5 Vdc to 4.5 Vdc output
Cover Ring Material      :      Polished Brass
Response Time      :      <5 ms
  • Ranges from 0 - 100 psi through 0 - 8000 psi
  • Stainless steel wetted parts
  • Stability <= +/-0.2% full scale per year, non-accumulating
  • Service life - >100000000 load cycles
  • Load limitations <= (Vpower-10)/0.02 A
  • Proof pressure 2 times full scale
  • Burst pressure 4 times full scale
  • Measuring element 17-4PH stainless steel
  • Electrical protection reverse polarity, over-voltage and short circuit protection
  • Shock 500 g according to IEC 60068-2-27
  • Vibration 20 g according to IEC 60068-2-6

Applications: Ideal for applications including hydraulics and pneumatics, mobile hydraulics, pumps and compressors, refrigeration controls and transportation
