NOSHOK® 623-2-1-1-2-6

NOSHOK® Pressure Transmitter, 0 psig to 2 psig, 0.25% Accuracy (BFSL), 4 mA to 20 mA Output, 1/4 NPT Male, 1/2 NPT Conduit w/ 6 ft Cable Attached

  • Manufacturers: NOSHOK
  • Brand Name: NOSHOK®
  • Tipco Part No: NOS 623-2-1-1-2-6
  • MPN: 623-2-1-1-2-6
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

NOSHOK® Pressure Transmitter, 0 psig to 2 psig, 0.25% Accuracy (BFSL), 4 mA to 20 mA Output, 1/4 NPT Male, 1/2 NPT Conduit w/ 6 ft Cable Attached

California residents see Prop 65 WARNINGS

Material      :      316 Stainless Steel
Product Type      :      Pressure Transmitter
Connection Size      :      1/4 in
Temperature Rating      :      -22 to 176 deg F Ambient, -40 to 212 deg F Media, -22 to 212 deg F Storage
Series      :      623 Series Pressure Transmitters
Connection Type      :      National Pipe Thread (NPT)
Enclosure      :      IP65/67
Pressure Low      :      0 PSI
Dimensions      :      1.06 in Dia x 4.25 in L
Pressure High      :      2 PSI
Connection Material      :      316 Stainless Steel
Ambient Temperature Low      :      -22 deg F
Ambient Temperature Low      :      -30 deg C
Ambient Temperature High      :      176 deg F
Ambient Temperature High      :      80 deg C
Pressure Range      :      0 - 2 psig
Operating Temperature Low      :      -22 deg F
Operating Temperature Low      :      -300 deg C
Process Connection      :      1/4 in MPT
Operating Temperature High      :      100 deg C
Operating Temperature High      :      212 deg F
Accuracy      :      +/-0.25% Full Scale (BFSL)
Media Temperature Low      :      -40 deg C
Media Temperature Low      :      -40 deg F
Power Required      :      10 - 30 VDC
Media Temperature High      :      100 deg C
Media Temperature High      :      212 deg F
Housing Material      :      316 Stainless Steel
Industry Standards      :      European Conformity (CE) Compliant to Electromagnetic Compatibility (EMC) Norm European Standards (EN) 61326:2014/A1:1998, Request for Information (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD) Protection
Output Signal      :      4 mA to 20 mA, 2-wire
Electrical Protection      :      Reverse polarity, over-voltage and short circuit protected
Electrical Connection      :      1/2 in. NPT male conduit with 6 ft integral cable
Service Life      :      > 100,000,000 Load Cycles
Vibration According to International Electrotechnical Commission (IEC) 60068-2-6      :      20 g
Shock According to International Electrotechnical Commission (IEC) 60068      :      1,000 g
Stability      :      = ±0.2% full scale for 1 year, non-accumulating
Compensated Temperature Low      :      0 deg C
Compensated Temperature Low      :      32 deg F
Compensated Temperature High      :      176 deg F
Compensated Temperature High      :      80 deg C
Cover Ring Material      :      Polished Brass
Response Time      :      =1 ms
  • Vacuum and compound ranges through 0 - 15000 psi, absolute ranges from 0 - 15 psi through 0 - 100 psi
  • 316 stainless steel and elgiloy wetted parts
  • Stability <= +/-0.2% full scale per year, non-accumulating
  • Service life - >100000000 load cycles
  • Load limitations <= (Vpower-10)/0.02 A
  • Proof pressure 3 times full scale
  • Burst pressure 3.8 times full scale
  • Measuring element 316 stainless steel
  • Electrical protection reverse polarity, over-voltage and short circuit protection
  • Shock 1000 g according to IEC 60068-2-27
  • Vibration 20 g according to IEC 60068-2-6

Applications: Ideal for applications including chemical processing, gas pressure measurement, oil field and offshore, mining and well head measurement
