AIRpipe 6771

AIRpipe 6771 Aluminum ANSI Reducing Flange, 63 mm Flange x 80 mm Pipe

  • Manufacturers: AIRpipe USA
  • Brand Name: AIRpipe
  • Tipco Part No: APU 6771
  • MPN: 6771
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

AIRpipe ANSI Reducing Flange, Connection Type 1: Flange, Connection Size 1: 63 mm, Connection Type 2: Pipe, Connection Size 2: 80 mm, 18 mm Bolt Hole Diameter, 8-Bolt Hole, Aluminum, Dimensions: 185 mm Dia x 87 mm L, -4 to 176 deg F

Fitting Type      :      Reducing Flange
Bolt Hole Diameter      :      18 mm
Number of Bolt Holes      :      8
Material      :      Aluminum
Dimensions      :      185 mm Dia x 87 mm L
Temperature Rating      :      -4 to 176 deg F
Connection 1      :      63 mm Flange
Connection 2      :      80 mm Pipe
Connection Type 1      :      Flange
Connection Type 2      :      Pipe
Connection Size 1      :      63 mm
Connection Size 2      :      80 mm
  • Includes (1) flange gasket and (8) 7 cm flange bolts

Standards/Certifications: ISO 8573-1 Specified
