Dixon® CFS800-1CS
Send Print
  1. pin-int

Dixon® CFS800-1CS

Dixon® King Crimp™ CFS800-1CS Carbon Steel Short Ferrule, 8 in, 8-29/64 - 8-36/64 in OD

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: DXN CFS800-1CS
  • MPN: CFS800-1CS
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® King Crimp™ Short Ferrule, Nominal Size: 8 in, 8-5/8 in ID, 8-29/64 - 8-36/64 in OD, 0.120 in Thick Wall, 4-1/4 in Length, Carbon Steel, For Use With: Dixon Frac Fittings

California residents see Prop 65 WARNINGS

Fitting Type      :      Ferrule
Material      :      Carbon Steel
For Use With      :      Dixon Frac Fittings
Nominal Size      :      8 in
Inside Diameter      :      8-5/8 in
Outside Diameter      :      8-29/64 - 8-36/64 in
Wall Thickness      :      0.120 in
Length      :      4-1/4 in

Safety Notes:

  • Due to differences in dimensions and tolerances for safety reasons, do not interchange other manufacturer's products with Dixon® products.
