Dixon® CS125-5CS

Dixon® King Crimp™ CS125-5CS Carbon Steel Sleeve, 1-1/4 in, 1-49/64 - 1-52/64 in OD

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: TIP FERRULE CS 1.875IN
  • MPN: CS125-5CS
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® King Crimp™ Sleeve, Nominal Size: 1-1/4 in, 1-7/8 in ID, 1-49/64 - 1-52/64 in OD, 0.06 in Thick Wall, 2-5/8 in Length, 300 psi, Carbon Steel, For Use With: Crimp Style Shanks

California residents see Prop 65 WARNINGS

Pressure Rating      :      300 psi
Material      :      Carbon Steel
For Use With      :      Crimp Style Shanks
Nominal Size      :      1-1/4 in
Inside Diameter      :      1-7/8 in
Outside Diameter      :      1-49/64 - 1-52/64 in
Wall Thickness      :      0.06 in
Length      :      2-5/8 in

Applications: For liquid service only

Safety Notes:

  • Only use the crimp style shanks with the crimp style sleeves and ferrules.
  • Due to differences in dimensions and tolerances for safety reasons, do not interchange other manufacturer's products with Dixon® products.
  • Pressure rating given at 70 deg F, consult Dixon for pressure rating at elevated temperatures.
