Legris by Dixon® Composite Mini Ball Valve, Nominal Size: 3/8 in, Actuator Type: Handle, Nylon, -4 to 175 deg F, 145 psi
California residents see Prop 65 WARNINGS
| Product Type | : | Ball Valve |
| Temperature Rating | : | -4 to 175 deg F |
| Pressure Rating | : | 145 psi |
| Nominal Size | : | 3/8 in |
| Actuator Type | : | Handle |
| Material | : | Nylon |
- Enables in-line opening and closing of a pneumatic circuit
- Suited to all types of installations
- Suitable fluid is compressed air
- Vacuum of 28 in-Hg
- Two-way, non-venting valve
- Compact and lightweight
- Screwdriver slot allows opening and closing even when access is difficult
- Handle is differentiated by a blue color and marked with the corresponding pneumatic symbol in order to enable immediate identification by the user
- Nickel-plated brass ball
