Dixon® 3-Way Diverting Standard-Port Ball Valve, Nominal Size: 1 in, Connection Type: FPT, Actuator Type: 1/4-Turn Handle, Brass, PTFE Trim, PTFE Seal, 3.74 in Length, 366 deg F, 400 psi
California residents see Prop 65 WARNINGS
| Product Type | : | Ball Valve |
| Length | : | 3.74 in |
| Temperature Rating | : | 366 deg F |
| Pressure Rating | : | 400 psi |
| Nominal Size | : | 1 in |
| Connection Type | : | FPT |
| Actuator Type | : | 1/4-Turn Handle |
| Material | : | Brass |
| Trim Material | : | PTFE |
| Seal Material | : | PTFE |
- T flow pattern
- Blowout-proof stem design
- Adjustable stem packing
- Chrome-plated brass ball
- PTFE seats, seals and thrust washers
- 1/4 turn handle can be adjusted to any orientation, notches on the valve stem reflect the three openings on the ball
Catalog/Catalog Cut Sheet
