Dixon® BBV100ST

Dixon® BBV100ST Bronze 250 lb Steam Standard-Port Ball Valve, 1 in FPT, 600 psi

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: DXN BBV100ST
  • MPN: BBV100ST
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® 250 lb Steam Standard-Port Ball Valve, Nominal Size: 1 in, Connection Type: FPT, Bronze, RPTFE Trim, 450 deg F, 600 psi

California residents see Prop 65 WARNINGS

Product Type      :      Ball Valve
Temperature Rating      :      450 deg F
Pressure Rating      :      600 psi
Nominal Size      :      1 in
Connection Type      :      FPT
Material      :      Bronze
Trim Material      :      RPTFE
  • Vacuum service to 29 in-Hg
  • Blowout-proof stem design
  • Adjustable packing gland
  • Bronze body
  • 316 stainless steel ball and stem
  • Multi-fill RPTFE seats
  • Multi-fill stuffing box ring
  • High temperature MTFE stem packing

Applications: For use with fluids with widely varying temperatures and/or thermal expansion rates
