Dixon® FBV50SE

Dixon® FBV50SE Brass Full-Port Ball Valve, 1/2 in Solder End, 600 psi

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: DXN FBV50SE
  • MPN: FBV50SE
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® Full-Port Ball Valve, Nominal Size: 1/2 in, Connection Type: Solder End, Brass, PTFE Trim, PTFE Seal, 366 deg F, 600 psi

California residents see Prop 65 WARNINGS

Product Type      :      Ball Valve
Temperature Rating      :      366 deg F
Pressure Rating      :      600 psi
Nominal Size      :      1/2 in
Connection Type      :      Solder End
Material      :      Brass
Trim Material      :      PTFE
Seal Material      :      PTFE
  • Blowout-proof stem design
  • Adjustable stem packing nut
  • Chrome-plated brass ball
  • PTFE seats, seals and thrust washers

Applications: For the best protection against potential gas leakage under extreme duty or low-pressure applications
