Dixon® 1WAYBV400

Dixon® MannTek 1WAYBV400 Aluminum 1-Way Full Flow Ball Valve, 4 in FPT, 150 psi

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: DXN 1WAYBV400
  • MPN: 1WAYBV400
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® MannTek 1-Way Full Flow Ball Valve, Nominal Size: 4 in, Connection Type: FPT, Aluminum, FPM Seal, 9-9/16 in Height, 6-11/16 in Width, 150 psi

California residents see Prop 65 WARNINGS

Product Type      :      Ball Valve
Height      :      9-9/16 in
Width      :      6-11/16 in
Pressure Rating      :      150 psi
Nominal Size      :      4 in
Connection Type      :      FPT
Material      :      Aluminum
Seal Material      :      FPM
  • High flow rate, low pressure drop
  • Spindle can be disassembled even when ball valve is installed
  • Two ports are one inlet and one outlet
  • Wetted parts are aluminum and stainless steel
