Aeroquip® 221501-20-16S
Send Print
  1. pin-int

Aeroquip® 221501-20-16S

Aeroquip® 221501 Dura-Kote Carbon Steel Straight Reducer, 1-1/4 in Female JIC x 1 in Male JIC

  • Manufacturers: Danfoss
  • Brand Name: Aeroquip®
  • Tipco Part No: AER 221501-20-16S
  • MPN: 221501-20-16S
  • UPC: 678146173874
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability
  • Due to supply chain constraints, TIPCO reserves the right to ship the Brennan equivalent of this part.

Aeroquip® 221501 Dura-Kote Carbon Steel Straight Reducer, Connection Size 1: 1-1/4 in, Gender 1: Female, Connection Type 1: JIC x Connection Size 2: 1 in, Gender 2: Male, Connection Type 2: JIC, -65 to 400 deg F

Series      :      221501
Connection Size 1      :      1-1/4 in
Connection Size 2      :      1 in
Gender 1      :      Female
Gender 2      :      Male
Connection 1      :      1-1/4 in JIC
Shape      :      Straight
Connection 2      :      1 in JIC
Thread Size 1      :      1-5/8-12
Thread Size 2      :      1-5/16-12
Finish      :      Dura-Kote
Dimension Standards      :      SAE 070123
Length      :      2.23 in
Fitting Type      :      Straight Reducer
Width      :      1.0625 in
Height      :      1.0625 in
Hex Size      :      2 in
Material      :      Carbon Steel
Temperature Rating      :      -65 to 400 deg F
Connection Type 1      :      JIC
Connection Type 2      :      JIC
