Dixon® G800-A-AL

Dixon® G800-A-AL Aluminum Global Cam and Groove Type A Adapter, 8 in Male Adapter x 8 in FNPT

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: DXN G800-A-AL
  • MPN: G800-A-AL
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® Global Cam and Groove Type A Adapter, Connection Type 1: Fitting, Gender 1: Male, Connection Size 1: 8 in, Connection Type 2: NPT, Gender 2: Female, Connection Size 2: 8 in, Thread Size 2: 8-8, 50 psi, Aluminum, Dimensions: 8-15/16 in Dia x 4-5/8 in L

California residents see Prop 65 WARNINGS

Fitting Shape      :      Type A
Connection Size 1      :      8 in
Connection Size 2      :      8 in
Thread Size 2      :      8-8
Pressure Rating      :      50 psi
Material      :      Aluminum
Dimensions      :      8-15/16 in Dia x 4-5/8 in L
Fitting Type      :      Adapter
Connection 1      :      8 in Fitting
Connection 2      :      8 in NPT
Connection Type 1      :      Fitting
Connection Type 2      :      NPT
Gender 1      :      Male
Gender 2      :      Female
  • Designed to interchange with all products produced to A-A-59326D

Applications: For use with liquids

Safety Notes:

  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Pressure rating is based on the seal of the mating part.
  • Pressure rating recommendations are based on the use of mating Dixon® fittings at ambient temperature 70 deg F with a standard seal installed.
  • For use at elevated temperature or other unusual operating conditions, consult Dixon®.
