Dixon® 5500G

Dixon® 5500 Anodized/Hard-Coated Aluminum API Coupler, 4 in TTMA Flange

  • Manufacturers: Dixon
  • Brand Name: Dixon®
  • Tipco Part No: DXN 5500G
  • MPN: 5500G
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Register to see Availability

Dixon® API Coupler, 5500 Series, Connection Type 1: TTMA Flange, Connection Size 1: 4 in, Aluminum, Finish: Anodized/Hard-Coated

California residents see Prop 65 WARNINGS

Connection Size 1      :      4 in
Material      :      Aluminum
Finish      :      Anodized/Hard-Coated
Fitting Type      :      Coupler
Series      :      5500
Connection 1      :      4 in TTMA Flange
Connection Type 1      :      TTMA Flange
  • Locking five-cam design for easy alignment and tight connection
  • 356T6 aluminum anodized hard-coat body
  • Replaceable nose seal can be changed without removing coupler from loading arm
  • Fully interlocked collar prevents fitting from opening when disconnected and from being disconnected while opened
  • 4 in TTMA inlet mounting flange connection
  • Ball-end handle for easy and comfortable operation
  • No special tools needed for maintenance
  • 5500 API rack coupler FKM-GFLT aluminum handle
  • Stainless steel cam
  • 356T6 aluminum anodized hard-coat poppet

Applications: For rail car and tank truck loading or unloading
