DIXON 2881217C
DIXON 2881217C Push-On Hose Barb With Plastic Cap, 3/4 in Hose Barbed x 3/4 in Female 37 deg JIC Swivel, Brass
- Manufacturers: Dixon Valve & Coupling Company, LLC
- Brand Name: DIXON
- Tipco Part No: DXN 2881217C
- MPN: 2881217C
- Min. Order Qty: 1
- Qty. Interval: 1
- Register to see Availability
DIXON Push-On Hose Barb, Hose Barb Fitting, 3/4 in Connection Size 1, Connection Type 1: Hose Barbed, 3/4 in Connection Size 2, Connection Type 2: Female 37 deg JIC Swivel, Barbed|Female JIC Swivel Connection, Brass, Material Construction: Brass, 1-1/16-12 Thread, 1-1/4 in Hex, 2.53 in L, 350 psi Maximum Operating Pressure, -40 to 150 deg F Operating Temperature
| Fitting Type | : | Hose Barb |
| Gender 2 | : | Female |
| Connection Size 2 | : | 3/4 in |
| Thread Size 2 | : | 1-1/16-12 UN |
| Hex Size | : | 1-1/4 in |
| Pressure Rating | : | 350 psi |
| Material | : | Brass |
| Dimensions | : | 2.53 in L |
| Dimension Standards | : | SAE J476, J512, J514, J516 |
| Temperature Rating | : | -40 to 150 deg F |
| Connection Type 1 | : | Hose Barbed |
| Connection Size 1 | : | 3/4 in |
| Connection 2 | : | 3/4 in JIC Swivel |
| Connection Type 2 | : | Female 37 deg JIC Swivel |
- Yellow plastic cap
